1. Direct Immersion nyob rau hauv lub tank, tsis muaj sab nraud chilled dej kav los yog twj tso kua mis
Lub evaporator ntawm cov khoom yog muab tso ncaj qha rau hauv lub tank kua. Lub peev xwm txias yog xa ncaj qha mus rau lub tank kua los ntawm cov evaporator nto. Rau cov dej tso tsheb hlau luam, cov tso tsheb hlau luam tshuaj, thiab cov chaw sim tso tsheb hlau luam uas muaj qhov chaw txwv lossis cov kav dej tsis yooj yim, qhov no yuav tsum zam cov kav dej txias sab nraud, twj tso kua mis, thiab kev teeb tsa lub tank dej.
2. Kev xaiv los ntawm Tank Volume thiab Thaum tshav kub kub Load
Kev xaiv yuav tsum muaj lub tank ntim, qhov kub ntawm cov dej pib, lub hom phiaj dej kub, lub sijhawm txias, thiab cov cua kub tsis tu ncua. SCA-01 (2.7 kW) yog siv rau chav dej da dej me me. SCA-03 (8.5 kW) thiab siab dua yog siv rau nruab nrab cov tso tsheb hlau luam. Yog tias lub tank muaj qhov hluav taws xob tas mus li, xaiv los ntawm cov khoom siv hluav taws xob tas li, tsis yog los ntawm lub tank ntim.
3. Stainless hlau Evaporator xaiv
Cov kua -cov evaporator sib cuag tuaj yeem yog stainless hlau. Nws yog haum rau dej-raws li coolant, qee cov kua tshuaj, thiab cov kua dej huv. Yog hais tias cov kua muaj corrosive Cheebtsam, hais cov nruab nrab hom ntawm kev txiav txim kom paub meej tias cov khoom compatibility.
- Laboratory tas li -tej dej kub da dej, qis- da dej kub
- Industrial tank kua txias, tshuaj kua ua kua txias
- Me me circulating dej tanks, ntxuav tank kub tswj
- Portable chiller chav txhawb nqa
Standard Configuration (Xaiv los ntawm Tank Volume)
|
Tank Volume (Reference) |
Pom zoo qauv |
Lub peev xwm txias |
Hwj chim |
Cov khoom siv evaporator |
|
Tsawg dua los yog sib npaug li 50 L |
SCA-01 |
2.7 kW 2 |
220/1/50 |
Stainless hlau |
|
50–150 L |
SCA-03 |
8,5 kW :os |
380/3/50 |
Stainless hlau |
|
150–300 L |
SCA-06 |
18 kWm |
380/3/50 |
Stainless hlau |
|
Ntau tshaj 300 L |
SCW-8 thiab siab dua |
21.5 kW thiab siab dua |
380/3/50 |
Stainless hlau / plhaub-thiab- raj |
Kev xaiv tiag tiag yuav tsum xav txog lub tank thawj zaug dej kub, lub hom phiaj dej kub, lub sij hawm txias, thiab cov cua kub tsis tu ncua. Muab lub tank qhov ntev thiab cov txheej txheem yuav tsum tau ua rau kev suav cov txheej txheem.
Suni txhawb OEM / ODM kev koom tes. Cov khoom tuaj yeem kho raws li tus neeg siv khoom tank qhov ntev, kua nruab nrab, thiab kev tswj qhov kub thiab txias. Cov khoom siv evaporator, fais fab mov, tswj txoj kev, thiab qhov ntev tuaj yeem hloov kho.
Yam tsawg kawg nkaus kom muaj nuj nqis yog 10 units. Cov qauv tuaj yeem muab tau tab sis raug them cais. Kev nug, qauv kev pom zoo, thiab cov lus hais tau teb hauv 12 teev.
- Hom logo thiab daim ntawv teev npe
- Evaporator khoom (stainless hlau thiab lwm yam)
- Fais fab mov (220V / 1 / 50Hz, 380V / 3 / 50Hz)
- Tswj txoj kev (digital kub maub los, PLC)
- Dimensions thiab immersion qhov tob
- Export packaging marking thiab manual language
cov khoom raug kuaj ua ntej xa khoom xa tuaj, tsom mus rau evaporator huab cua- nruj thiab rwb thaiv tsev kev ua tau zoo, kom paub meej tias tsis muaj hluav taws xob thiab tsis muaj hluav taws xob xau tom qab immersion.
Txhua chav tsev yog lub tshuab nqus tsev vacuum kuaj ua ntej them lub tub yees. Tom qab them nyiaj, qhov ntsuas kub ceev thiab ntsuas qhov ntsuas kub raug kuaj. Cov khoom siv hluav taws xob yog rwb thaiv tsev ntsuas raws li kev tiv thaiv cov dej noo. Cov ntawv xeem raug suav nrog.
Q: Puas tuaj yeem tso dej tso rau hauv lub tank ncaj qha rau hauv cov kua dej?
A: Paub meej cov tshuaj muaj pes tsawg leeg, concentration, thiab kub ntau yam. Cov kua -cov evaporator sib cuag tuaj yeem yog stainless hlau. Nws yog haum rau dej -raws li coolant thiab ib co kua tshuaj. Yog hais tias cov kua muaj cov kua qaub, muaj zog alkali, los yog corrosive Cheebtsam, hais qhov no ntawm kev txiav txim kom paub tseeb tias cov ntaub ntawv compatibility los yog xav kom ib tug cais lub tes tsho.
Q: Dab tsi yog qhov sib txawv ntawm qhov sib txawv ntawm lub tshuab dej submersible thiab tus qauv chiller?
A: Tus qauv chiller xav tau cov kav dej txias sab nraud thiab lub twj tso kua mis xa dej txias rau hauv lub tank lossis khoom siv. Ib yam khoom tso cov evaporator ncaj qha rau hauv lub tank, tsis muaj cov kav dej txias sab nraud thiab lub twj tso kua mis. Kev teeb tsa yooj yim dua. Qhov hluav taws xob xav tau kev tiv thaiv noo noo thiab tsis haum rau cov nplaim taws lossis tawg ua kua.
