1. Cua txias muaj peev xwm 300–1200 W
SAS300 txog SAS1200 suav nrog 8 qauv. Lub peev xwm txias txias yog 300, 400, 450, 500, 600, 800, 1000, thiab 1200 W. Cov neeg yuav khoom tuaj yeem xaiv raws li tag nrho cov khoom siv hluav taws xob ntawm inverters, PLCs, relays, thiab lwm yam khoom siv hauv cov tswj vaj huam sib luag.
2. Phab ntsa-Mounted Installation, Tsis muaj Internal Vaj Huam Sib Luag Chaw Ua Haujlwm
SAS series siv phab ntsa -mounted installation. Lub tsev loj yog sab nraum lub txee. Tsuas yog lub qhov hluav taws xob cua thiab rov qab cua inlet txuas mus rau sab hauv ntawm lub txee. Rau cov tswj vaj huam sib luag nrog cov khoom ntom ntom, tsis muaj qhov chaw txuas ntxiv hauv vaj huam sib luag.
3. Kev tiv thaiv qib IP54/IP55
SAS300 rau SAS1000 sab hauv thiab sab nraud tiv thaiv qib yog IP54. SAS 1200 yog IP55. Nws yog siv rau kev tswj vaj huam sib luag kub tswj hauv kev lag luam plua plav thiab av noo ib puag ncig.
4. Suab nrov 55–65 dB(A)
SAS series suab nrov yog 55-65 dB (A). Nws tuaj yeem raug ntsia ntawm ib sab ntawm cov khoom siv lossis hauv ib lub rooj cob qhia yam tsis muaj chav tshuab cais.
- Lub thawv me me, tswj vaj huam sib luag cua txias
- Hluav taws xob txee txias khoom txhawb nqa
- Tswj vaj huam sib luag txias, vaj huam sib luag txias
- Industrial txee cua txias, tswj vaj huam sib luag cua txias units
Standard Configuration (SAS Control Vaj Huam Sib Luag Txias Chav, Xaiv Cov Qauv)
|
Parameter |
Chav tsev |
SAS 300 |
SAS 450 |
SAS 600 |
SAS 1000 |
|
Lub peev xwm txias |
W |
300 |
450 |
600 |
1000 |
|
Fais fab mov |
V/ph/Hz |
220/1/50 |
220/1/50 |
220/1/50 |
220/1/50 |
|
Cov tub yees |
- |
R22/R134A |
Ib yam |
Ib yam |
Ib yam |
|
Kev tiv thaiv qib (hauv / sab nraud) |
IP |
IP54 / IP54 |
IP54 / IP54 |
IP54 / IP54 |
IP55 / IP55 |
|
Suab nrov |
dB (A) |
55 |
55 |
60 |
60 |
|
Qhov Loj (W × H × D) |
mm |
287×446×185 |
287×500×185 |
350×630×205 |
361×745×215 |
- Fais fab mov: 220V / 1 / 50Hz (lwm yam specifications negotiable)
- Cov tub yees: R22, R134A
- Dimensions thiab xim (batch xaj)
- Lub logo thiab daim ntawv lo
- Kev tiv thaiv qib hloov kho (los ntawm qhov project yuav tsum tau)
- Export packaging marking thiab manual language
Export xaj yog tsau nrog cov rooj ntoo lossis pallets. Lub qhov hluav taws xob cua thiab rov qab cua nkag tau them nrog lub kaus mom tiv thaiv thaum thauj mus los tiv thaiv cov khoom txawv teb chaws nkag. Cov ntawv qhia, daim ntawv pov thawj, cov npe ntim khoom, thiab cov ntawv xeem raug suav nrog. Txhua qhov kev txiav txim raug pov hwm nrog kev pov hwm thauj mus los.
Yog tias muaj kev puas tsuaj tshwm sim thaum tuaj txog, muab rau ntawm - cov duab hauv chaw thiab cov ntaub ntawv tau txais kos npe tam sim.
Q: Cov khib nyiab txias puas tuaj yeem siv rau cov neeg rau zaub mov racks?
A: Yog. SAS series txee sab hauv kub yog +25℃rau +38 degree, haum rau servers, network khoom, thiab lwm yam khoom siv hluav taws xob ua haujlwm ib puag ncig. Kev xaiv yuav tsum tau lees paub tag nrho cov khoom siv hluav taws xob nyob rau hauv lub khib nyiab, khib nyiab sealing, thiab qhov chaw nruab. Yog tias cov khoom siv hluav taws xob ntau tshaj 1200 W, xaiv SAH series hluav taws xob txee txias los yog sab laj cov neeg ua haujlwm.
Q: Dab tsi yog qhov txawv ntawm chav txias txias thiab lub server khib txias chav tsev?
A: Ob leeg muaj qhov ua haujlwm zoo ib yam, siv rau kev tswj qhov kub thiab txias. A server product usually targets high heat generation and high density server rack scenarios, possibly with higher air flow or redundancy design. Rau cov racks zoo tib yam lossis cov khoom siv racks, xaiv SAS series. Rau cov neeg rau zaub mov racks, muab cov npe khoom siv thiab cov khoom siv hluav taws xob rau kev suav.
